Kemtrak FL007 Oil-in-Water Analyzer

The Kemtrak FL007 oil-in-water analyzer utilizes both fluorescence and turbidity measurements to deliver reliable and accurate readings of oil and hydrocarbon contamination levels in water. Suitable for the most challenging applications, the FL007 has a low cost of ownership and high return on investment.

DISCUSS SOLUTIONS WITH US

THE KEMTRAK FL007 IS A RELIABLE SOLUTION FOR OIL-IN-WATER DETECTION AND MEASUREMENT

Unlike most oil-in-water analyzers, the Kemtrak FL007 can simultaneously measure both the fluorescence and the turbidity of a sample. This is useful because combining fluorescence and turbidity measurements assures reliable continuous monitoring of oil and hydrocarbon contamination in water.

The fluorescence measurement is used to monitor the presence of aromatic hydrocarbons while a dual turbidity measurement monitors aliphatic oils in the stream.

The combined fluorescence and turbidity measurement capability of the FL007 analyzer makes it ideal for:

  • Trace oil-in-water detection
  • Leak detection
  • Heat exchanger cooling water & condensate return
  • Drinking water purity
  • Wastewater monitoring
  • Environmental monitoring

Taking the mystery out of measuring trace oil in water:

Video Thumb

KEMTRAK FL007 OIL-IN-WATER ANALYZER

The Kemtrak FL007 is a fiber optic-based oil-in-water analyzer. It uses a unique combined fluorescence and turbidity measurement technique to assure reliable continuous monitoring of oil and hydrocarbon contamination in water, whether aromatic or aliphatic in nature. The Kemtrak FL007 utilizes a robust industrial backscatter probe with a sapphire window in a Ø12mm PG13.5 “pH sensor style” pattern for ease of installation into pipes and vessels through existing ports/adapters.

Oils rich in aromatic content fluoresce when illuminated with ultraviolet light, and the intensity of this fluorescence depends on the quantity and characteristics of the polyaromatic hydrocarbon (PAH) being monitored. Both free oil and dispersed oil can be measured for a total oil-in-water measurement, while solids and gas bubbles are essentially ignored. Oils that fluoresce include fuel oil, crude oil, hydraulic oil and transformer oil.

For oils with a low water solubility and for those that do not fluoresce, the FL007 also uses a turbidity measurement technique to monitor oil content. The FL007's unique dual measurement technique provides a repeatable and high confidence measurement/detection of oil in water when deployed in the field.

Typical Applications: Trace oil in water, Heat exchanger leak detection, cooling water and condensate return, wastewater monitoring, environmental discharge monitoring, and more.

  • FL007

FL007

Kemtrak FL007

FL007

Operating Wavelength Dependent upon application
Measurement Range
Fluorescence: 0–5,000 μg/L PAHphe
(ca. 0 – 200 ppm oil in water)
Turbidity: 0 – 10,000 FTU
(ca. 0 – 20,000 ppm oil in water)
Detection Limit / Resolution
Fluorescence: 0–5,000 μg/L PAHphe
Turbidity: < ± 0.5 FTU
Accuracy ± 2% of reading
